Durable, reliable and affordable mobile terminal


The OPH-3001 is designed to make scanning a comfortable experience, especially if scanning is required often. The ergonomic design includes a soft grip, a curved scan head for relieve stress from the wrists and a bright display for better readability. But this scanner is still a mobile scanning device, capable of running complex applications.

Frequent scanning can strain the wrist, that is why we designed the OPH-3001. With the curved scan head, soft grip and bright readable screen it is clear this scanner is designed with the user in mind. With a strong processor this handheld mobile computer is perfectly capable of running complex applications, best suited for your situation. This advanced product is programmable to perform to your liking, thus, becoming the perfect solution in the workplace. It has a LCD screen with adjustable brightness so that in every condition the screen is perfectly readable.

Features of the OPH-3001

A few highlights that make this data collector an enjoyable scanning experience:

  • Ergonomic design with curved scan head and soft grip
  • Bright display for easy reading
  • Clear scanning feedback with LED and buzzer
  • Lightweight

The OPH-3001 is often used by tasks that require frequent scanning because the ergonomic design is known to reduce wrist strain that happens with any repetitive action. The uses include: keeping track of inventory, managing assets or mobile sales automation. Complex applications for specialized tasks can be built using the free SDK facilitated by Opticon.

Additional information

Form factor

Reading type

Operating system


2”, 320 x 240 pixels, TFT LCD QVGA color display with backlight


Communication interface



Ver 1.2 physical layer, baurate 1200 bps – 115.2 kbps


USB, ver. 2.0, VCP / MSD / HID

Light source

650 nm visable laser diode

Scan rate

100 scans / seconds

Drop test

1.5 m / 5 ft drop onto concrete surface

IP rating

Dimensions (WxHxD)

58.2 x 180.8 x 23.8 mm / 2.29 x 7.12 x 0.94 in

Weight body

Ca. 156 g / 5.5 oz (incl. battery)

Product compliance

CE, FCC, RoHS, IEC60825-1 Class 2, FDA CDRH Class II, EN55022, EN55024


Wrist strap, USB cable, standard battery
